Yesterday (6 Jan), someone showed off a small clever puzzle game on Hacker News, called enclose.horse.
An example puzzle looks like this:
The game is played on a grid of grass or water tiles. The goal is to place walls so that the horse cannot escape (i.e. exit the map) whilst keeping the area of the enclosure as large as possible.
(By “escape”, we mean here that no path should exist between the horse and the map border. There are no time dynamics present here; as this seemed to confused some readers of the HN post.)
Walls can only be placed on grass tiles, and the horse cannot traverse over water either. The neighborhood is a von Neumann one. The score is calculated as the number of tiles in the enclosure (including the one the horse stands on). Interesting extra: tiles can also contain a cherry, on which no walls can be placed either but which add an additional three points if they are within the enclosure.
Just as I’ve done in the past, I wanted to have a quick stab towards finding the optimal solution using the CP-SAT constraint programming solver, which is part of Google’s OR Tools. My initial feeling was that the “flood fill” would be hard to tackle and/or the solve time would be large for this grid size, but CP-SAT has no trouble with it.
First, we perform some necessary imports, load in a level from a daily, and parse the map:
from ortools.sat.python import cp_model
import requests
def parse_map(map_str: str):
lines = [ln.rstrip("\n") for ln in map_str.splitlines() if ln.strip() != ""]
if not lines:
raise ValueError("Empty map string")
N = len(lines[0])
for k, ln in enumerate(lines):
if len(ln) != N:
raise ValueError(f"Ragged map: line {k} has len {len(ln)} != {N}")
M = len(lines)
grid_water = [[0] * N for _ in range(M)]
is_cherry = [[0] * N for _ in range(M)]
horse_pos = None
for i, ln in enumerate(lines):
for j, ch in enumerate(ln):
if ch == "~":
grid_water[i][j] = 1
elif ch == "H":
if horse_pos is not None:
raise ValueError("Multiple horses 'H' found")
horse_pos = (i, j)
elif ch == "C":
is_cherry[i][j] = 1
# '.' or anything else -> empty
if horse_pos is None:
raise ValueError("No horse 'H' found")
return lines, grid_water, horse_pos, is_cherry
if __name__ == "__main__":
url = "https://enclose.horse/api/daily/2026-01-07"
data = requests.get(url).json()
print("Parsing map...")
lines, grid_water, horse_pos, is_cherry = parse_map(data["map"])
print("Solving...")
status, score, walls, region = solve(
grid_water, horse_pos, is_cherry, data["budget"], time_limit_s=30
)
print("Status:", status)
print("Score:", score)
print("Walls:", len(walls))
print(render_solution(lines, grid_water, is_cherry, horse_pos, walls, region))
Next, we can implement the solve function itself:
def solve(grid_water, horse_pos, is_cherry, wall_budget, time_limit_s=10, log=False):
M = len(grid_water)
N = len(grid_water[0]) if M else 0
hi, hj = horse_pos
def in_bounds(i, j):
return 0 <= i < M and 0 <= j < N
def is_border(i, j):
return i == 0 or j == 0 or i == M - 1 or j == N - 1
if not in_bounds(hi, hj):
raise ValueError("horse out of bounds")
if grid_water[hi][hj] == 1:
raise ValueError("horse cannot be on water")
model = cp_model.CpModel()
neighbors = [(1, 0), (-1, 0), (0, 1), (0, -1)]
w, r, passable = {}, {}, {}
for i in range(M):
for j in range(N):
water = (grid_water[i][j] == 1)
cherry = (is_cherry[i][j] == 1)
r[i, j] = model.NewBoolVar(f"r_{i}_{j}")
if water:
w[i, j] = model.NewConstant(0)
passable[i, j] = model.NewConstant(0)
model.Add(r[i, j] == 0)
continue
# No walls on horse/cherry
if (i, j) == (hi, hj) or cherry:
w[i, j] = model.NewConstant(0)
else:
w[i, j] = model.NewBoolVar(f"w_{i}_{j}")
# For non-water: passable + wall = 1
passable[i, j] = model.NewBoolVar(f"p_{i}_{j}")
model.Add(passable[i, j] + w[i, j] == 1)
# Reachable implies passable
model.Add(r[i, j] <= passable[i, j])
# Horse must be reachable
model.Add(r[hi, hj] == 1)
# Constrict hore: no reachable border
for i in range(M):
for j in range(N):
if is_border(i, j):
model.Add(r[i, j] == 0)
# Wall budget
model.Add(sum(w[i, j] for i in range(M) for j in range(N)) <= wall_budget)
# r[u] ∧ passable[v] => r[v]
for i in range(M):
for j in range(N):
for di, dj in neighbors:
ni, nj = i + di, j + dj
if in_bounds(ni, nj):
model.AddImplication(r[i, j], r[ni, nj]).OnlyEnforceIf(passable[ni, nj])
# Objective: cherries add +3
weights = {}
for i in range(M):
for j in range(N):
if grid_water[i][j] == 1:
weights[i, j] = 0
else:
weights[i, j] = 4 if is_cherry[i][j] == 1 else 1
model.Maximize(
sum(weights[i, j] * r[i, j] for i in range(M) for j in range(N))
)
solver = cp_model.CpSolver()
solver.parameters.max_time_in_seconds = float(time_limit_s)
solver.parameters.log_search_progress = bool(log)
solver.parameters.log_to_stdout = bool(log)
status = solver.Solve(model)
status_name = solver.StatusName(status)
if status not in (cp_model.OPTIMAL, cp_model.FEASIBLE):
return status_name, 0, set(), set()
score = 0
walls_set, reachable_set = set(), set()
for i in range(M):
for j in range(N):
if solver.Value(r[i, j]) == 1:
reachable_set.add((i, j))
score += weights[i, j]
if grid_water[i][j] == 0 and is_cherry[i][j] == 0 and (i, j) != (hi, hj) and solver.Value(w[i, j]) == 1:
walls_set.add((i, j))
return status_name, score, walls_set, reachable_set
This base setup is actually rather simple. Our main decision boolean just determines where we place walls. Two auxiliary variables keep track of which tiles are reachable/passable.
- The horse tile must be reachable
- A tile being reachable implies it is passable
- For each reachable tile and a passable neighbor, we imply that the neighbor is also reachable
Finally, we can render out the solution:
# No queens on the same diagonal
for r in range(ROWS - 1):
for c in range(COLS):
if c > 0:
model.Add(solution[r + 1][c - 1] == 0).OnlyEnforceIf(solution[r][c])
if c < COLS - 1:
model.Add(solution[r + 1][c + 1] == 0).OnlyEnforceIf(solution[r][c])
And we can solve and print out a solution:
def render_solution(lines, grid_water, is_cherry, horse_pos, walls_set, reachable_set):
M = len(lines)
N = len(lines[0]) if M else 0
hi, hj = horse_pos
out = []
for i in range(M):
row = []
for j in range(N):
if (i, j) == (hi, hj):
row.append("🐎")
elif grid_water[i][j] == 1:
row.append("🟦")
elif (i, j) in walls_set:
row.append("🧱")
elif is_cherry[i][j] == 1:
row.append("🍒")
else:
row.append("🍃" if (i, j) in reachable_set else "⬜")
out.append("".join(row))
return "\n".join(out)
This seems to work well:
Status: OPTIMAL
Score: 66
Walls: 12
🟦🟦⬜🧱🟦🟦🟦🧱🟦🟦🟦🟦
🟦🍒🧱🍒🍃🍃🍃🍃🍃🍃🍃🟦
⬜⬜🍒🧱🍃🍃🍃🍃🍃🟦🍃🧱
⬜🍒⬜🍒🟦🟦🍃🍃🟦🟦🍃🟦
🟦⬜🟦⬜🟦🟦🍃🍃🍃🍃🍃🟦
🟦⬜⬜🧱🍃🍃🍃🍃🍃🍃🍃🟦
⬜⬜⬜⬜🟦🍃🟦🟦🍃🍃🍃🟦
🟦⬜⬜⬜🟦🟦🐎🟦🍃🍃🍃🧱
🟦⬜⬜⬜⬜🧱🍃🍃🍃🍃🍃🧱
🟦⬜⬜⬜⬜⬜🟦🟦🍃🍃🍃🟦
⬜⬜🟦🟦⬜⬜🟦🟦🍒🍃🍒🟦
🟦⬜🟦⬜⬜⬜⬜⬜🧱🍒🍃🟦
🟦⬜⬜⬜⬜⬜⬜⬜🍒🧱🍒🟦
🟦⬜🟦🟦⬜🟦⬜🟦⬜⬜🧱🟦
And indeed as verified by the daily:
However, as a user pointed out to me, this can end up being problematic for maps such as this one:
Score: 53
Walls: 6
🟦🟦🟦🟦🟦🟦🟦🟦🟦🟦🟦🟦
🟦🍃🍃🍃🍃🍃🍃🍃🍃🍃🍃🟦
🟦🍃🍃🍃🍃🍃🍃🍃🍃🍃🍃🟦
🟦🍃🍃🍃🍃🍃🍃🍃🍃🍃🍃🟦
🟦🍃🍃🍃🍃🍃🍃🍃🍃🍃🍃🟦
🟦🍃🍃🍃🍃🍃🍃🍃🍃🍃🍃🟦
🟦🍃🟦🟦🟦🟦🟦🟦🟦🟦🍃🟦
⬜🧱⬜⬜⬜⬜⬜⬜⬜⬜🧱⬜
⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜
⬜⬜⬜⬜⬜🧱⬜⬜⬜⬜⬜⬜
⬜⬜⬜⬜🧱🐎🧱⬜⬜⬜⬜⬜
⬜⬜⬜⬜⬜🧱⬜⬜⬜⬜⬜⬜
The problem is the closing off of “horseless areas”, since the solver can freely assign these to be reachable as well, erroneously adding these to the objective.
Hence, we also need to add single flow commodity constraints, flowing from the horse:
# Prevent unconnected island by single commodity flow
K = M * N
flows = {}
neighbors = [(1,0), (-1,0), (0,1), (0,-1)]
# directed edge flows
for i in range(M):
for j in range(N):
for di, dj in neighbors:
ni, nj = i + di, j + dj
if 0 <= ni < M and 0 <= nj < N:
f = model.NewIntVar(0, K, f"f_{i}_{j}_to_{ni}_{nj}")
flows[(i, j, ni, nj)] = f
# We can only send flow along reachable & passable cells
model.Add(f <= K * r[i, j])
model.Add(f <= K * r[ni, nj])
total_reached = sum(r[i, j] for i in range(M) for j in range(N))
for i in range(M):
for j in range(N):
inflow = []
outflow = []
for di, dj in neighbors:
pi, pj = i - di, j - dj
ni, nj = i + di, j + dj
if 0 <= pi < M and 0 <= pj < N:
inflow.append(flows[(pi, pj, i, j)])
if 0 <= ni < M and 0 <= nj < N:
outflow.append(flows[(i, j, ni, nj)])
if (i, j) == (hi, hj):
# Horse supplies exactly total_reached - 1
model.Add(sum(outflow) - sum(inflow) == total_reached - 1)
else:
# Each reachable node consumes 1
model.Add(sum(inflow) - sum(outflow) == r[i, j])
Solving again, we now get the true correct solution:
Score: 2
Walls: 6
🟦🟦🟦🟦🟦🟦🟦🟦🟦🟦🟦🟦
🟦⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜🟦
🟦⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜🟦
🟦⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜🟦
🟦⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜🟦
🟦⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜🟦
🟦⬜🟦🟦🟦🟦🟦🟦🟦🟦⬜🟦
⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜
⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜⬜
⬜⬜⬜⬜⬜🧱🧱⬜⬜⬜⬜⬜
⬜⬜⬜⬜🧱🐎🍃🧱⬜⬜⬜⬜
⬜⬜⬜⬜⬜🧱🧱⬜⬜⬜⬜⬜
